| Project | Content | Specification |
| Satellite Tracking | Satellite System [1] | GPS+BDS+Glonass+Galileo+QZSS, Supports Beidou Gen 3, Five satellites, twenty-one frequency points |
| Satellite Tracking | Satellite Tracking | BDS: B1I,B2I,B3I,B1C,B2a,B2b*
GPS: L1C/A,L1C,L2C,L2P,L5 GLONASS: G1,G2,G3 Galileo: E1,E5a,E5b,E6* QZSS: L1C/A,L1C,L2C,L5 IRNSS: L5* SBAS: L1C/A* |
| Channel Number | 1408 | |
| Initialization Reliability | 99.99% | |
| Satellite-based Differential (Optional) | Operable without network | |
| Anti-Interference | Narrow-band anti-interference technology, effectively shields internal electromagnetic interference | |
| Offline Continuation | Supported | |
| Accuracy [2] | Static Accuracy | Planar Accuracy: ±(2.5mm + 0.5×10^-6×D)mm <br> Elevation Accuracy: ±(5mm + 0.5×10^-6×D)mm |
| RTK Accuracy | Planar Accuracy: ±(8mm + 1×10^-6×D)mm <br> Elevation Accuracy: ±(15mm + 1×10^-6×D)mm | |
| Tilt Measurement Accuracy | 8mm + 0.3 mm/° tilt | |
| Real Scene Measurement Accuracy | Typical 2~4cm, measuring distance 2~15 meters | |
| GNSS+INS | IMU Update Rate | 200Hz |
| Tilt Angle | 0-60° | |
| User Interaction | LCD Screen | Near-retina display, Color HD 1.1 inch OLED; <br> Resolution: 126*294; Clear and bright under direct sunlight |
| Indicator Lights | 1 satellite light + 1 differential data light | |
| Buttons | Fn function key + Power/confirm key | |
| Web Interface | Supports PC/mobile webpages | |
| Voice | Supports voice broadcast in handbook | |
| Camera | Pixel | 2MP & 5MP |
| Frame Rate | 25Hz | |
| Field of View | 75° | |
| Physical Properties | Size | Φ152 mm x 81 mm |
| Weight | 1.06Kg | |
| Material | Magnesium alloy | |
| Operating Temperature | -45℃ to +75℃ | |
| Storage Temperature | -55℃ to +85℃ | |
| Waterproof and Dustproof | IP68 | |
| Impact Resistance | IK08 | |
| Condensation Resistance | 100.00% | |
| Electrical Performance [3] | Battery | Mobile station typical endurance 18 hours |
| Fast Charging | Maximum 24w fast charging. Charge for 1 hour, restores 50% battery, works for 8 hours | |
| External Power Supply | DC 9-28V | |
| Storage | 8GB, supports external expansion up to 128GB (USB/TF card) | |
| Electronic Bubble | Supported | |
| Wireless Communication | Wireless Connection | Supports NFC, Bluetooth, Wi-Fi touch flash connection receiver |
| eSIM | Supports dual-network eSIM in the main unit and handbook | |
| Network | 4G full Netcom | |
| WiFi | IEEE 802.11a/b/g/n/ac | |
| Bluetooth | 5.0 and 4.2 +EDR, backward compatible | |
| Radio | Built-in transceiver radio, supports various mainstream radio protocols | |
| Control Handbook | Model | HCE600 Android Measurement Handbook |
| Operating System | Android 10 | |
| CPU | Octa-core 2.0GHz processor | |
| LCD Screen | 5.5” HD display | |
| Battery | Typical endurance 14 hours | |
| Waterproof and Dustproof | IP68 |
Note:
[1] *Frequency points can be supported through firmware upgrades.
[2] Measurement accuracy is obtained in a normal environment, and reliability is affected by factors such as tilt angle, number of satellites, geometric distribution, ionosphere, etc.; Non-standard operations such as rapid rotation and high-intensity vibration may affect inertial navigation accuracy.
[3] Battery life is related to the working environment, working temperature, and working mode. The current conditions are for standard operation.
